Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed

Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed
Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed

Grande immagine :  Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed

Dettagli:
Luogo di origine: Cina
Termini di pagamento e spedizione:
Quantità di ordine minimo: 1

Liyi Universal Testing Machine with 1200mm Effective Pull Space 220V/50HZ Power and 0.5~1000mm/min Test Speed

descrizione
Precisione: 0,5% Energia: 750W
Classe di protezione: IP56 Voltaggio: 380 V, 220 V, 240 V, 110 V.
Capacità: 1,2,5,10,20,50.100.200.500.1000,2000 kg (5000 kg, 4t personalizzabile) Spazio di trazione efficace: 1200 mm (contenere impugnature)
Peso: 145 kg Alimentazione elettrica: 220V/50Hz
Velocità di prova: 0,5 ~ 1000 mm/min Gamma di test: 400mm MAX
Risoluzione: 1/250.000 Motore: Panasonic Servo Motor
Capacità di carico massima: 5000 kg Errore relativo della forza: ± 0,5%
Test Actus: 1200 mm
Evidenziare:

1200mm Effective Pull Space Universal Testing Machine

,

220V/50HZ Power Tensile Testing Machine

,

0.5~1000mm/min Test Speed UTM

Liyi UTM Tension Compression Peel Strength Universal Tensile Testing Machine
The Liyi UTM Universal Tensile Testing Machine is designed for comprehensive material testing, including tensile strength, compression, elongation, stripping force, tear strength, and bending strength measurements for both finished and semi-finished products.
Technical Specifications
Model LY-1066A LY-1066B
Accuracy Class 0.5 (with Verified Certificate)
Optional Load Cell 1,2,5,10,20,50,100,200,500,1000,2000,5000kg
Max Load Capacity 5000KG 2000KG
Resolution 1/250,000 1/150,000
Force Relative Error ±0.5%
Test Speed Range 0.1~500mm/min 50~500mm/min
Motor Panasonic Servo Motor AC Inverter Motor
Test Stroke (contain clamps) 1200mm
Product Images
Company Profile
Dongguan Liyi Environmental Technology Co., Ltd is a high-tech production-oriented enterprise specializing in developing, manufacturing, and marketing various environmental testing equipment. With advanced technology, experienced personnel, and a comprehensive quality management system, we serve customers in over 150 countries.
Our product range includes simulated environmental testers, plastic and rubber testers, and other material testing equipment. Based in Dongguan, Guangdong province (China's manufacturing center), we also maintain an office in Kunshan, Jiangsu province to better serve Eastern China markets.
Frequently Asked Questions
Are you the manufacturer? What after-sales service and warranty do you offer?
Yes, we are a professional manufacturer of testing equipment. All machines come with a 12-month warranty (extended to 14 months for overseas shipments). We provide free maintenance during this period and offer technical support via email or video chat, with solutions typically provided within 24-48 hours of problem identification.
What is your standard delivery time?
Standard machines are typically available from stock. For non-stock items, delivery time is 15-20 working days after deposit receipt. We can accommodate urgent requests with special arrangements.
Do you accept customization and OEM services?
Yes, we offer both standard and customized machines according to customer requirements, including OEM/ODM services with your logo on the equipment.
How do I install and use the machine?
Most machines are shipped fully assembled - just connect the power cable to begin use. We provide English operation videos via email and can assist with on-site installation when necessary.
